使用方案 (Product Solution) | MT8127 |
操作系统 (Operating System) | Android™ 4.4.2 |
| |
| 规格 (Specification) |
| CPU | ARM | MTK8127 Cortex A7*4 1.3GHz |
| GPU | 2D/3D | 支持Open GL ES 2.0 |
| VPU | 视频编码和解码 (Video encoding and decoding) | 解码支持4倍高清的格式有:MPEG1/2/4、H.264、H.263、VC-1、AVS、VP8,解码支持全格式的1080P高清解码。编码支持H.264格式1080P的编码。 (Decoding 4x HD format: MPEG1/2/4, H.264, H.263, VC-1, AVS, VP8 to, decoding 1080P HDdecoding to support the whole format. Encoding support 1080P encoding of the H.264 format.) |
显示屏 (Display) | 尺寸 (Size) | 7 英寸 (7 inches) |
| 分辨率 (Resolution) | 800*480像素 (800 * 480 pixels) |
| 色彩 (Color) | 262114 色 (262114-color) |
| 背光 (Backlight) | LED |
存储器 (Memory & Flash) | 内存 (Memory) | Lpowerddr2 512MB/ |
固态硬盘 (Solid-state disk) | MLC Nand Flash /8GB,内置MLC控制器,最高可以支持到64bit ECC SLC/MLC/TLC 15MB/s (MLC Nand Flash /8GB, built-in MLC controllers can support up to 64bit of ECC SLC / MLC / TLC 15MB/s |
电能规格 (Power and Battery) | 适配器 (Adapter) | AC 100~240V,DC 5V / 2A MINI USB socket |
| 车充(Car Charger) | DC +12V,DC +5V, 2A, MINI USB socket |
| 电池类型 (Battery Type) | 锂电池(可充电) Lithium Battery (Rechargeable) |
工作电流 (Working current) | 580-800mA/3.7V背光最亮(Backlight Brightest) |
| 330-370mA/3.7V背光最暗(Backlight Darkest) |
| 550-800mA/3.7V播放MP3(play mp3) |
| 最大工作电流 (Maximum Working current) | <1.45A |
| 待机电流(Suspendcurrent) | <5mA |
| 充电电流(Charging current) | 最大1050mA |
电池容量 (Battery capacity) | 3.7V/850-3000mAh |
电池续航时间 (Battery life) | 大约1-6小时(7")(Approximately 5-6 hours) |
GPS/wifi/BT/FM接收四合一 (MT6627) | 内置GPS接收模块 (Built-in GPS Receiver) | Ordering Information | MT6627 |
| 定位精度 (PositionAccuracy) | Without Aid: 10 m 2D-RMS |
| 速度精度 Velocity Accuracy | Without Aid: 0.1 m/s |
| 加速精度 Acceleration Accuracy | Without Aid: 0.1 m/s2 |
| 时间精度 Timing Accuracy | < 100 ns |
| 灵敏度 (Sensitivity | Tracking:-159 dBm Hot Start:-159 dBm Warm Start: -159dBm Cold Start: :-159dBm Autonomous Acquisition: -145dBm |
| 首次定位时间 TTFF (Time To First Fix) | Cold Start: < 45 s (Autonomous) Warm Start: < 35 s Hot Start: < 2 s |
| 重新获取时间Reacquisition Time | < 1 s |
| 最大高度 Maximum Altitude | 18,000 m |
| 最大加速度 Maximum Acceleration | 4 G |
| 最大速度 Maximum Velocity | 515 m/s |
| Wi-Fi | * Operates in 2.4 GHz frequency bands,B/ G /N * 1x1 MIMO technology improves effective throughput and range existing 802.11 b/g products * Data rates: up to 150Mbps * 802.11e-compatible bursting and I standards * BPSK, QPSK, 16 QAM, 64 QAM modulation schemes * WEP, TKIP, and AES, WPA, WPA2 hardware encryption schemes |
| BT | YES |
| FM接收 | YES |
| FM | 内置Fm发射 | KT0806 76MHz~108MHz |
| Gravity sensor | 内置重力感应 | MC3230:± 1.5g range 1 to 128 samples/sec |
| 扬声器 (Speaker) | 1* 1W / 8Ω |
外设接口 (Peripheral Interface) | SD 卡槽 (SD card slot) | 支持SD1.0到SD3.0,MMC3.3到4.3 (Support SD1.0 to SD3.0 , MMC3.3 to 4.3) |
| USB | USB 2.0 Host x 1 / OTG x 1 |
| USB | USB2.0, high speed, |
| USB host | External U disk connection,MP3,MP4,storage device such as mobile hard disk can play directly Supports external 3G USB-dongle wireless internet card |
| |
| | | | |
| | | | |
| 摄像头(Camera) | 单录200W(OV2710 |
| 内置AV IN(Built-inAVIN) | 有 |
| 话筒(Microphone) | 可录音 (Recordable) |
| | | |
| | |
| | | | | | |
| 输入设备(Input device) | 多点电容屏 (Multi-points capacitive screen) |
通过USB接口,支持鼠标和键盘输入。 (Support for mouse and keyboard input via the USB interface) |
| 多媒体支持 (Multimedia) | Video Player | Supports Super high definition 2160P,Supports MKV,AVI,WMV,RMVB,TS,TP,M2TS,RM,MPEG,VOB,MOV,FLV,MP4,3GP,DAT,PMP format for video play. |
| Ebook Reader | TXT,LRC,PDF,HTML,HTM,EPUG,PDF,FB2 |
| Audio Player | WMA, MP3,OGG,APE,FLAC,AAC,WAV |
| Photo Viewer | JPG, BMP,PNG,GIF |
| | 配件 | 适配器(Car adapter),USB连接线(USB Cable),说明书(user manual),支架(mounting bracket),旅行充电器(Travel charger)/可选(optional),SD卡(SD Card)/可选(optional), |
| 指示灯(LED Indicator) | 充电红灯,充满时绿灯(Charging:Red on ,Battery Full:Red off and Green on) |
| 温度(Temperature) | Operation: -10~60°C |
| 尺寸规格(Dimensions) | PCB :180mm×110mm*26mm |
| | | | | | |
| | | | | | |
