full hd 1080p.h.264 mpeg-4/avc Free to air digital dvb-t2 receiver

Chipset Sunplus 1509c chipset solution

Features

1.DVB-T2/DVB-T compatible, supports MPEG4

2. Compatible with 576i/576p/720p/1080i/1080P video formats

3. Auto and manually scan all available TV and radio channels,Parental guidance locking

4. Auto/manual program search, multi-language supported, VBI Teletext.

5. Supports MPEG-1, MPEG-2, MPEG-4 and H.264 decoder (up to 1,920 x 1,080 pixels)

6. Advanced audio processor supporting Dolby Digital and Dolby Digital Plus (optional)

7. USB2.0 host support upgrade, PVR, time shifting and media play with U-Flash or HDD

8. Supports HDMI output, scart output, coaxial, RF in and output

9.Powerful and highly effective 7days EPG function

Tuner

*Input Frequency: VHF 174~230 MHZ, UFH 470~ 862 MHZ

*Input Frequency: VHF 174~230 MHZ, UFH 470~ 862 MHZ

*RF input level: -78~20 dBm

*RF Bandwidth: 7MHZ and 8MHZ

*Signal input: IEC-type female

*QPSK, 16QAM,64QAM, 256QAM

*FEC: 1/2, 2/3, 3/4, 4/5, 5/6

Multimedia format

*RF input level: -78~20 dBm

*RF Bandwidth: 7MHZ and 8MHZ

*Signal input: IEC-type female

*QPSK, 16QAM,64QAM, 256QAM

*FEC: 1/2, 2/3, 3/4, 4/5, 5/6

*Audio Codec: WMA,MP3,AAC (.wma,.mp3,m4a)

*Photo Codec: JPEG, BMP, PNG

Power

*Maximum power consumption:< 10w *Standby power: <1w

Packing

Packing : 1 Color Box

Color box : 198*155*58mm

Qty per export carton : 40pcs pieces

Meas. per export carton : 63*33.5*22cm

G.W:10.46KG
