| Product Description |
|
| INPUT |
voltage range |
100-240VAC |
| frequency range |
47-63Hz |
| standby power |
1A |
| efficiency |
DOE VI /V |
| AC input current |
1.5A max at 230VAC at full load |
| Irush current |
30A Max. @110Vac/60Hz |
| 60A Max. @230Vac/50Hz |
| OUTPUT |
DC voltage range |
12.6v max |
| voltage range |
±5% |
| load current |
5a max |
| range power |
66w max |
| voltage tolerance |
±5% |
| line regulation |
±1% |
| load regulation |
±5% |
| AC Plug |
US EU |
UK |
| AU JP |
Other |
| KOREA CHINA |
|
| DC Plug straight Lshape |
5.5*2.1 |
Mini USB MICRO |
| 5.5*2.5 |
Crocodile clip red+ black- |
| 4.0*1.7 |
AVIATION HEAD |
| 3.5*1.35 |
Double and line |
| TYPE-C |
lotus skill |
| 2.0*0.7 |
other as your requirment |
| DC CORD |
1m/1.2m /1.5m / 1.8m /2m /3m |
other as your requirment |
| PROTECTION |
over voltage protection |
|
| over current protection |
|
| short circuit |
|
| SAFETY APPROVALS |
UL62368/ UL60950/ UL1310/ CE/ GS/ SAA/ KC KCC/ PSE/ RCM |
|
| MTBF |
50000 hours |
|
| WARRANTY |
36 months |
|
| LED indicator light |
unloaded green light /red light |
|
| operating temperature |
0°c-40°c |
storage temperature :-20c-85°c |
| protection |
With short-circut protection |
over current protection |
| test |
100 full load burn-in test |
|
| PACKAGE |
PE bag and white box |
|
| Carton Size |
46*39*26cm |
|
