| Production Series |
TK-E86GC |
| An overview of the |
Design style fashion simple, clear and smooth lines extend the current mobile intelligent terminal equipment mainstream modeling of.PV material + metal shell and bottom of multicolor after smooth transition appearance match processing. Electroplating metal texture surface shell produce different visual effects, with the ARM Cortex-A7 4 core @1.3Ghz processor.8.0 inch mainstream HD IPS display both nowadays intelligent mobile. All equipment function and processing ability. |
| Features |
1, 8.0 inch high performance to price ratio A7 quad flat computer; 2, to support the GPS location, radio, telephone, GSM, bluetooth; 3, dual cameras; 4, support for dual card dual standby; 5, IPS HD resolution of 800*1280; 6, support, distance sensing light. |
| Configurations |
CPU |
CORTEX-A7 Octa core(1.3GHZ) MTK6592 |
| GPU |
Mali-400,up to 400MHz |
| OS |
Android 5.1 |
| Memory |
1GB DDR3 |
| ROM Flash |
16GB(Optioan:32GB) |
| Ext. Storage |
T-Flash(Up to 32GB) |
| Panel |
Size |
8.0" 16:9 |
| Resolution |
1280*800 |
| Touch Panel |
5 points capacitive touch screen |
| IO |
USB |
1 MicroUSB;support charging |
| Headphone |
1 Φ3.5mm |
| TF Card |
1 pcs Micro SD Card |
| Communication |
WIFI |
802.11 b/g/n |
| Bluetooth |
4.0+EDR |
| 2G |
Support for 2G band |
| 3G |
Support WCDMA 850/2100 |
| Audio&Video |
Camera |
2.0M Camera front with 5.0M Camera back |
| Speaker |
8R/1W 1pcs |
| MIC |
Built-in |
| Power |
The charging current |
USB input DC5V@2A |
| Battery |
3200mAh、3.7v lithium battery |
| Stand-by Time |
90h |
| Operate Time |
>5h |
| Human-computer Interaction |
G-Sensor |
Support |
| Buttons |
1 power button,2 volume buttons |
| Appearance |
Dimension |
208.9*120.1*8.6mm |
| Weigh |
About 320g
|
