Total Resistance Range

全阻抗范围

1-2MK

Total Resistance Tolerance

全阻误差值

±20%

Resistance Taper

阻抗特性型式

A,B,C

Max. Operation Voltage

最高工程电压

50V AC 20V AC

Rated Power

负载功率

0.05W

Sliding Noise

滑动噪声

Less than 100 mV (Test speed:30r/min)

Insulation Resistance

绝缘阻抗值

More than 100 MΩ  at DC 250 V

Withstand Voltage

耐电压特性

1 minute at AC 250 V

Residual Resistance

残留阻抗值

Less than 20Ω,抗硫化：50Ω以下

Gang Error(Dual Unit models)

同步误差值（双联机种）

-30 dB～0 dB:±2dB

Total Rotation Angle

全回转角度

300度 ±10度

Rotation Torque

旋转力矩

20～200 gf.cm(Test speed:60度/Sec)

Rotation Stopper Strength

旋转止动强度

3.0Kgf.cm Min.

Less than 3 seconds

3秒以内

Push-Pull Strength

轴柄推拉承受强度

5.0 Kg.f Min.

Click Torque

段位推动力

30～300 gf.cm

Applicable with +CC mondels

+CC机种适用

Bushing & Nut tight Strength

轴套螺母紧固强度

8.0Kgf.cm.min

Applicable with bushing & nut models

带轴套，螺母机种适用

Resistance to soldering heat

焊锡耐热性

Manual Soldering: Less than 250 and quicker than 3 seconds.250℃以下，3秒以内

Durability Rotational Life

耐久次数值

10000 Cycles Min
