Rated Line Pull

12000LBS (5443kgs) single line

Motor

4.8kw/6.5hp,series wound

Control

Remote switch, 9.8ft(3m)lead

Gear train

3 Stage Planetary

Gear train ratio

265:1

Clutch

Sliding Ring Gear

Braking Action

Automatic In-The-Drum

Drum Size

Φ2.5"(64)mm×(8.8")223.5mm

Cable

Φ9.1mmX26m

Overall Dimensions

19.8"x6.3"x8.5"(527mm×160mm×217mm)

Mounting Bolt Pattern

255mm×114mm   Φ11

Weight

N.W.37kg    G.W.38Kg

Packing Size

610×350×270mm

Line pull lbs(kgs)

Line speed ft/min(m/min)

Current A

0

 24.9(7.6)

80

2000(907)

16.1(4.9)

180

4000(1814)

10.8(3.3)

240

6000(2722)

 8.5(2.6)

280

8000(3628)

 7.2(2.2)

330

10000(4536)

 5.9(1.8)

380

12000(5443)

 5.2(1.6)

400
