150M产品特点

150M无线传输速率

QSS快速安全设置，符合WPS，轻松设置无线安全

20/40MHz频道共存，使性能成倍增强

兼容11g、11b设备，通过迅驰兼容性测试

硬件优先级服务，确保带宽敏感的任务优先处理

强大的WPA/WPA2、WPA-PSK/WPA2-PSK安全机制，支持WEP加密

简单易用的用户管理软件，轻松配置无线客户端

产品描述

   150M无线USB网卡符合IEEE 802.11n（Draft 2.0）、IEEE 802.11g、IEEE 802.11b标准，

无线传输速率高达150Mbps。【（内-外）置智能天线】，提供更好的无线传输性能、稳定性和无线覆盖范围。

同时采用CCA技术，能自动避开频道干扰并充分利用频道捆绑优势。该产品支持64/128/152位WEP加密

，以及WPA/WPA2、WPA-PSK/WPA2-PSK等高级加密与安全机制，同时具有QSS快速安全设置功能，符合WPS，

能够轻松设置无线安全。此外，该产品具有优先级服务功能，确保视频、语音等带宽敏感数据的优先处理

。该产品与11g产品及其它11n产品也能够很好地兼容。

产品规格

支持的标准和协议IEEE 802.11g、IEEE 802.11b、IEEE 802.11n（draft 2.0）无线技术、CSMA/CA with ACK

总线类型USB 2.0

频率范围2.4～2.4835GHz

传输速率11n： 可达150Mbps

11g：6/9/12/18/24/36/48/54Mbps（自适应）

11b：1/2/5.5/11Mbps（自适应）

工作信道数13

数据调制11b：CCK,DQPSK,DBPSK

11g：OFDM

11n：OFDM with PSK,BPSK,16-QAM,64-QAM

RF功率20dBm（最大值）

天线增益2dBi(内置式)

指示灯Status

外型尺寸68*20*8.7mm

使用环境工作温度：0℃到40℃

存储温度：-40℃到70℃

工作湿度：10%到90%RH不凝结

存储湿度：5%到90%RH不凝结

支持操作系统Windows 2000/XP/Vista/WIN 7/WIN CE/LINUX/MAC OS

Description：

150MWireless USB network adapter in line with the IEEE 802.11n (Draft 2.0),

IEEE802.11g, IEEE 802.11b standard, wireless transfer rate up to 150Mbps.

2 built-in smart antennas, wireless transmission to provide a better performance,

stability, and wireless coverage. At the same time,

CCA technology used to automatically avoid the channel

interference and make full use of advantages of channel bundling. The product

support 64/128/152 bit WEP encryption, as well as WPA/WPA2,

WPA-PSK/WPA2-PSK advanced encryption and security mechanism,

fast and secure at the same time QSS capabilities, in line with the WPS,

can easily set up wireless security. In addition,

the product has priority service functions to ensure that video,

voice and other sensitive data bandwidth priority.

The products and11gproducts and other 11n products are compatible with well.

Product Features：

Complies with IEEE 802.11n(draft 2.0), IEEE802.11g, IEEE 802.11b standards

1x1/1x2 modes

STBC Support for Extended Range

150Mbps RX PHY Rate, 150Mbps TX PHY Rate

Support

Legacy and High Throughput Modes

20MHz/40MHz bandwidth

Reverse Direction Data Flow and Frame Aggregation

WEP 64/128, WPA, WPA2 Support

QoS ¤C WMM, WMM-PS

Multiple BSSID Support

Provides USB 2.0 Hi-Speed interface

Cisco CCX V1.0 V2.0 V3.0 Compliance

Bluetooth Co-existence

Low Power with Advanced Power Management

Operating Systems - win2000 win2003 winxp vista32 vista64 wince5.0 wince6.0 win7 linux mac(10.3/10.4/10.5)

Internal Antenna
